- 内置MPPT太阳能控制器
- 纯正弦波输出
- 工频设计
- 拨码开关可设置交流电电压输入范围和低电池动作电压
- 输出功率因数0.9-1和输出插座可以选择
- 很好兼容发电机接入并自动启动
- 全自动静音运转
- 电池和市电自动转换
- 微处理芯片为可靠动行提供高效保障
- 远程控制，BTS功能（可选）
- 最大充电电流可达85A可通过前面板调整
- 充电模式优先可以设置
- 电池类型可通过前面板选择
- 低电池电压保护，过载保护，输出短路保护和过温保护，抑制浪涌干扰，消除噪音
SPECIFICATION:
|
MODEL |
FSS-OSI 1-6KW |
||||||
|
1KW |
1.5KW |
2KW |
3KW |
4KW |
5KW |
6KW |
|
|
Input wave form |
Sine wave (utility or generator) |
||||||
|
Normal voltage |
120VAC(option) 230VAC |
||||||
|
Low voltage re trip |
90V±4% & 184V/154V±4% |
||||||
|
Low voltage re engage |
100V±4% & 194V/164V±4% |
||||||
|
High voltage re trip |
140V±4% & 253V±4% |
||||||
|
High voltage re engage |
135V±4% & 243V±4% |
||||||
|
Normal input frequency |
50Hz/ 60Hz (auto detection) |
||||||
|
Frequency range |
47Hz ~65Hz |
||||||
|
Output Wave form |
(Bypass mode)same as input |
||||||
|
Over-Load Protection |
Circuit breaker |
||||||
|
Short circuit Protection |
Circuit breaker |
||||||
|
Efficiency on line transfer mode |
>95% |
||||||
|
Line transfer time |
10ms Typical |
||||||
|
Bypass without battery connected |
Yes |
||||||
|
Inverter output |
|||||||
|
Output wave form |
Pure sine wave |
||||||
|
Output continuos power (watts) |
1000 |
1500 |
2000 |
3000 |
4000 |
5000 |
6000 |
|
Output continuos power (VA) |
1000 |
1500 |
2000 |
3000 |
4000 |
5000 |
6000 |
|
Power factor |
0.9-1.0 |
||||||
|
Nominal Output Voltage (rms) |
120VAC(option) 230VAC |
||||||
|
Output Voltage regulation |
+/- 10%rms |
||||||
|
Output frequency |
50Hz ± 0.3Hz or 60Hz ± 0.3Hz |
||||||
|
Short circuit Protection |
Yes ,fault after 1 secs |
||||||
|
Inverter specification/input |
|||||||
|
Nominal input voltage |
12V/24V/48V |
||||||
|
Minimum start voltage |
10V/20V/40V |
||||||
|
Low battery alarm |
10.5V/21V/42V |
||||||
|
Low battery trip |
10V/20V/40V |
||||||
|
High voltage alarm |
16V/32V/64V |
||||||
|
Charger |
|||||||
|
Output voltage |
Dependent on battery type |
||||||
|
Charge current |
10-85A MAX |
||||||
|
Battery initial voltage for start up |
0-15.7v for 12v(*2 for 24v;*4 for 48v) |
||||||
|
Over charge protection |
15.7v for 12v(*2 for 24v;*4 for 48v) |
||||||
|
Solar Charge |
|||||||
|
MPPT Range@Operating Voltage |
15VDC~150VDC / 25VDC~150VDC / 60VDC~150VDC |
||||||
|
Maximum PV Array Open Circuit Voltage |
150VDC |
||||||
|
Maximum Charging Current |
40A/60A |
||||||
|
Maximum Effciency |
>96% |
||||||
|
Standby Power Consumption |
2W |
||||||
